STATE GS650YBDS 50-GALLON, DV NATURAL GAS, WATER HEATER, 40,000 BTU
NO SERIAL NUMBER | VENT NOT INCLUDEDcall 417-626-8208 or fill out the form for a freight quoteResidential Gas Water HeaterType TallApplicable Standard ASHRAE/IESNA 90.1, ANSI Z21.10.1, CSA 4.1, NAECA, UBC, CEC, SBCC, BOCA, HUDInlet/Outlet Connection 3/4" M
Category: Natural Gas Water Heaters
NO SERIAL NUMBER | VENT NOT INCLUDED
call 417-626-8208 or fill out the form for a freight quote
- Residential Gas Water Heater
- Type Tall
- Applicable Standard ASHRAE/IESNA 90.1, ANSI Z21.10.1, CSA 4.1, NAECA, UBC, CEC, SBCC, BOCA, HUD
- Inlet/Outlet Connection 3/4″ Male Threaded x 3/4″ Male Threaded
- Gas Type Natural
- Relief Valve Details T and P Relief Valve Factory Installed
- Venting Type Direct
- Draft Hood Outlet/Vent Size 6″
- Input Supply Rating 40000 BTU/HR
- Tank Dimensions 22″ Diameter x 59″ Height
- Tank Height Including Draft Hood 73″
- Tank Material Glass Lined
- Tank Capacity 50 Gallon
- GPH Recovery 43 GPH at 90 Deg F
- Ignition Type Push Button Piezo
- Drain Valve Details Tamper Resistant Brass
- Insulation Details Thick CFC Free Foam
- Burner Type Green Choice Low Nox
- Energy Saver Conformance No
- Inclusions/Features Intelligent Control Logic, Self-Powered Electronic Gas Valve, Diagnostics, Diffuser Dip Tube, CoreGar Anode Rod
- Energy Factor 0.59
