DODGE F2B-SCEZ-115-PCR SCEZ Series E-Z Kleen Normal-Duty 2-Bolt Polymer Housed Flange Unit

PRODUCT DISCLOSURE:

All products were acquired by from a sale of merchandise subject to a commercial insurance loss. is a secondary seller of products, is not affiliated with or sponsored by the manufacturer of the products and is not a manufacturer authorized seller of the products. Sale of this product by is not subject to the policies of the manufacturer. Any warranty offered by the manufacturer is not available to you as the purchaser. All products are NEVER USED but external packaging will have damage. Some items may be placed into other packaging to ensure safe shipping. All items are opened for inspection prior to shipment to ensure the best quality of products. guarantees your satisfaction. If you are not completely satisfied with a purchased product, within 30 days from the date of purchase, return the product in its packaging and will fully refund your money.

External Packaging has been subjected to smoke damages. Parts are inspected and cleanedif needed, prior to shipment. All parts are NEW/NEVER USED and fully functional.

PRODUCT DETAILS

• 2-Bolt Flange
• 1 15/16 in Shaft
• 6 3/16 in Bolt Spacing
• Polymer Housing
• Setscrew Locking Collar

DESCRIPTION

• Corrosion-resistant polymer housed ball bearing

APPLICATIONS

• Wet, cool and cold side environments
• Food and beverage
• Pharmaceutical packaging
• Processing industries

FEATURES

• Inner and outer rings are precision hardened and honed for wear resistance and quiet operation
• Patented Maxlife cage is made from a high temperature polymer material, and its one-of-a-kind, compartmentalized design ensures that grease pockets are maintained around the balls, leading to less likelihood for grease washout and cooler operating tempera
• Anti-rotation pin makes insert replacement easier with no need to replace grease fittings or location pins
• 65 setscrew spacing offers an optimum balance between locking force and inner ring stress
• Grade 10 balls for quieter operation and less vibration

COMPLIANCES

• 0

SPECIFICATIONS

BEARING DESIGN Non-Expansion HOUSING CONSTRUCTION 1 Piece FLANGE TYPE 2-Bolt Flange LOCKING DEVICE Setscrew Locking Collar HOUSING MATERIAL Polymer INCH/METRIC Inch MISALIGNMENT RANGE 2 FLANGE THICKNESS 0.765625 in COLLAR EXTENSION 19/32 in MOUNTED UNIT DUTY Corrosion Resistant-Duty BOLT HOLE SPACING 6 3/16 in LUBRICATION Relubricatable BOLT SIZE 5/8 BEARING TYPE Ball Bearing HOUSING HEIGHT 4 1/2 in SEAL TYPE PROGUARD Plus Contact Seals w/Flingers INSERT TYPE Corrosion-Resistant Insert LENGTH THROUGH BORE 1.75 in SHAFT DIA. 1.9375 in HOUSING LENGTH 7 31/64 in END TYPE Open End OVERALL WIDTH 2 11/64 in COLLAR O.D. 2 7/16 in OUTER RING SIZE 210 WEIGHT 3.6 LB EAN OR UPC 782475985197
