Interchange TDXL110/06, Net Weight (lbs) 0.20 Pressure 15-60 PSI Brand Greenleaf Technologies

GreenLeaf TurboDrop

110 Flat Fan Multi-purpose Medium Pressure Air Induction Nozzle

Greenleaf Technologies patented TurboDrop technology may be the most important addition you can make to your sprayer. TurboDrop has been proven commercially over17 years of use in over40 countries around the world.The TurboDrop Nozzlecan dramatically improve your application of crop protection chemicals.

TheTurboDrop XL Medium Pressure Nozzleoffers a unique combination of superior drift control and excellent coverage, making it an ideal choice for all of your spraying applications.

TheTurboDrop XL Nozzlecan operate between 20 and 120 psi, with an optimal pressure range of 30-90 psi. This range allows you to increase your GPA rate without changing nozzles. To reduce off target movement with pre-emerge and systemic products, 30-70 psi is recommended. To improve coverage and penetration with contact chemicals, 60-120+ psi is recommended. To be even more precise, target ASABE Coarse droplets for pre-emerge and systemic products, and medium droplets for coverage critical chemicals.

TheTurboDrop XL Venturican also be used with other spray tips. Simply double the size of extended range, twin fan, and flood or off center nozzles. For example, the 03 Venturi uses 11006 spray tip.Remember the Venturi controls the flow rate, and the tip creates the pattern.

The TurboDrop Nozzle is also available in a ceramic version, theTurboDrop TDCXL, with a ceramic metering orifice in the Venturi, enabling an extended wear life of 50-80,000 acres. BothTurboDrop XLand theTDCXLhave been proven to outlast stainless steel tips.TurboDrop XL Nozzlesare available in sizes 01 through 10, and are ISO color coded for easy identification.

Wide Pressure Range: TDXL 20-120psi
TDCXL 30-150psi Wide Drift Control Range: Sizes 01-02: 20-60+ psi
Sizes 025-04: 20-80+ psi
Sizes 05-10: 20-100+ psi Separate Injector (Venturi) Comes apart by hand, easy to clean (no tools required). Patented Stabilization Chamber Even and uniform mixing of air with liquid which gives a tighter, more uniform droplet spectrum and a homogeneous spray solution across a wide operating range. Excellent With Rate Controllers Wide pressure range allows greatest speed variations. Improved Coverage, Reduced Runoff Air-filled droplets spread on the target surface rather than bouncing off. Reduced Clogging Round metering orifice versus elliptical slit. Interchangeable Tip / Cap Two spray nozzles in one. Other tips may also be used. Proven TurboDrop Technology Over 17 Years in 40 countries. Longer Wear Life TDXL: 20-30,000 Acres
TDCXL: 60-80,000Acres Patented Pulsation Dampener Stable, uniform spray pattern across pressure range gives good patternation and coverage. Widest Variety of Applications Recommended for herbicides, fungicides, insecticides, fertilizers, growth regulators, etc. More Spray on Target Dramatic reduction of off-target movement, even in higher winds. May Lower Water Usage Both air and water are used as a carrier. (Excellent for Glyphosate at 5-10 GPA) Approved for Bayer’s Liberty herbicide TurboDrop XL and Airmix AM are the only air induction nozzles recommended by Bayer for their contact herbicides.
