SWL 190 DL-BQ

Interchange 15 Inch,402-190510,402190754,7000 lb,Direct Weld,Side Wind, Net Weight (lbs) 23.50 Product Link1 /Specs/402-190754.pdf Product Link2 /Specs/402-190754_l.pdf Specification Brand: Bulldog Part Number: 190754 Warranty: Limited 5 Year Warranty UPC: 086693907543 Dimensions: 27″ L x 8″ W x 8″ H Weight: 26 lbs. Handle Style: Sidewind Capacity: 8,000 lbs. Travel: 15 in. Retracted: 25.06 in. Extended: 53.56 in. Model No.: SWL 190 DL-BQ Feature description Use this BULLDOGtrailer jack to replace broken or rusted jacks on your agricultural, livestock, or utility trailers. This jack was designed to be compact, yet still has 8,000 lbs. of support capacity. The compact design allows this replacement to fit into tight spaces. Brand Bulldog

Side Wind Square Tube Bulldog Trailer Jack

BULLDOG’s 8,000 lbs. support capacity square jack serves the agricultural, industrial, construction, horse/livestock trailer, and utility/cargo trailer markets. The compact design of these jacks makes them ideal for tight-fitting applications where 3″ and 4″ square tube jacks are too big!

• Use the painted outer tube as the final finish or primer
• Zinc-plated inner tube and drop leg
• 4.7″ Outer / inner tube overlap – results in optimal side load performance
• 5/8″ screw stem – provides insurance against screw stem twisting off
• Sidewind model – 1/4″ cross pin connects gear train to screw stem – guards against shearing jack pin
• Sidewind model – 1:1.33 gear ratio
