WalterWCGT32.52 FN2 Grade WNN10 Carbide Turning Insert

Proprietary Finish, 80 Trigon, 3/8″ Inscr Circle, 5/32″ Thick, 0.031″ Corner Radius

PRODUCT DISCLOSURE:

All products were acquired by from a sale of merchandise subject to a commercial insurance loss. is a secondary seller of products, is not affiliated with or sponsored by the manufacturer of the products and is not a manufacturer authorized seller of the products. Sale of this product by is not subject to the policies of the manufacturer. Any warranty offered by the manufacturer is not available to you as the purchaser. All products are NEVER USED but external packaging will have damage. Some items may be placed into other packaging to ensure safe shipping. All items are opened for inspection prior to shipment to ensure the best quality of products. guarantees your satisfaction. If you are not completely satisfied with a purchased product, within 30 days from the date of purchase, return the product in its packaging and will fully refund your money.

MSC Part #: 31006257Mfr Part #: 6955679

Features and Benefits

Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.

Specs

Insert Style WCGT Insert Size 32.52 Material Carbide Length (Decimal Inch) 0.2570 Inscribed Circle (Inch) 3/8 Thickness (Inch) 5/32 Corner Radius (Decimal Inch) 0.0310 Manufacturer’s Grade WNN10 Coating Proprietary Chip Breaker FN2 Insert Length (Decimal Inch) 0.2570 Overall Length (Decimal Inch) 0.2570 Hole Diameter (Decimal Inch) 0.1730 ISO Number WCGT06T308-FN2 WNN10 Relief Angle 7 Coating Process PVD Manufacturers Catalog Number 6955679 Included Angle 80 Cutting Direction Neutral Insert Hand Neutral Series WCGT Maximum Depth of Cut (Decimal Inch) 0.2570 Cutting Width (mm) 6.52 Shape Trigon
